Professional LED Moving Head Light – Powerful Performance & Stunning Versatility
Elevate your stage productions and events with our high-performance 280W LED Moving Head Light, designed for exceptional brightness, precision, and dynamic effects. With a 20,000-hour lifespan and energy-efficient 350W power consumption, this fixture delivers brilliant illumination while reducing long-term costs.
✔ 280W High-Output LED – Crisp, vibrant lighting with smooth 0-100% dimming
✔ Advanced Optical System – Zoom (2.8°–33°), frost filter, and 3-facet rotating prism for stunning beam shaping
✔ Rich Creative Effects – 8-color wheel, 12 static + 7 rotating gobos, and 0-25Hz strobe for dynamic shows
✔ Ultra-Precise Movement – 540° pan / 270° tilt with 16-bit precision for flawless tracking
✔ Multiple Control Modes – DMX512 (16/20CH), RDM, master/slave, and self-propelled modes for seamless integration
✔ Robust & Reliable – Axial fan cooling and high-temp resistant housing ensure durability in -20°C to 40°C environments
Concerts & Festivals – Command attention with sharp beams and vibrant colors
Theaters & Stages – Enhance performances with smooth dimming and gobo projections
Nightclubs & Events – Create immersive atmospheres with prism effects and fast strobes
Weddings & Architectural Lighting – Soft frost mode delivers elegant, natural washes
Compact yet powerful (14.5kg), this moving head is your go-to lighting solution for professional-grade impact. Upgrade your setup today!
(Fixture Dimensions: 340×220×520mm | Packed: 420×300×580mm)
Input Voltage: AC 100–240V, 50/60Hz (Auto-Switching)
Power Consumption: 350W (Rated)
Light Source: 280W High-Output LED (20,000-hour lifespan)
Beam Adjustment: Zoom range 2.8°–33° (Motorized)
Frost Effect: Dedicated frost filter (Soft-edge light diffusion)
Color System:
Color Wheel: 8 interchangeable colors + Open
Fixed Gobo Wheel: 12 replaceable gobos + Open
Rotating Gobo Wheel: 7 glass gobos + Open (Bi-directional variable-speed rotation)
Prism: 3-facet rotating prism (Bi-directional, variable speed)
Dimmer: 0–100% linear dimming
Strobe: Adjustable 0–25Hz (Sync/Macro capable)
Macro Effects: Pre-programmed sequences, self-run, master/slave modes
Pan/Tilt:
Pan (Horizontal): 540° (16-bit precision)
Tilt (Vertical): 270° (16-bit precision)
Electronic error correction
Control Protocols: DMX512 (16/20CH), RDM support
Addressing: Manual dial/LCD menu
Software: Field-upgradable firmware
LCD Panel: Backlit display with tactile navigation
Cooling System: High-efficiency axial fan
Housing: High-temperature-resistant engineered polymer
Operating Temp: -20°C to +40°C
Fixture: 340mm (L) × 220mm (W) × 520mm (H)
Packaging: 420mm (L) × 300mm (W) × 580mm (H)
Net Weight: 14.5 kg | Gross Weight: 16.5 kg
Combined multi-element optical lens system
Silent operation with advanced heat dissipation
Compliance with international DMX/RDM standards
