The PRC-PBL1815 is an IP65 waterproof LED wall wash light built for demanding outdoor applications. Equipped with 18×15W RGBWA+UV 6-in-1 pixel-controllable LEDs, it delivers smooth color mixing, UV effects, and dynamic chases. Selectable beam angles (15°–60°) offer flexibility for any installation.
Housed in a rugged die-cast aluminum body with passive cooling and an OLED touch screen, it supports multiple DMX modes (up to 110 channels), strobe, dimming, auto and sound-active programs.
Usage Scenarios: Perfect for architectural facades, bridges, theme parks, outdoor stages, shopping malls, and large-scale events.
Lightweight (7.6 kg) and reliable, the PRC-PBL1815 is an ideal choice for lighting professionals seeking weather-resistant, pixel-mappable wash lights.
Model Name: PRC-PBL1815
Product Name: IP65 Waterpoof LED Wall Wash Light
● Power Voltage: AC110V–240V, 50/60Hz
● LED Type: 18pcs × 15W RGBWA+UV 6in1 LEDs (Pixel controllable)
● Beam Angle: 15°/30°/45°/60° (selectable)
● DMX Modes: 6 / 8 / 11 / 108 / 110 channels
● DMX Functions: Single pixel control, strobe, dimmer, static color, color macro, color temperature correction, auto program, sound-active programs
● Control Modes: DMX512, auto program, sound-active program, master/slave
● Cooling: Passive cooling via die-cast housing heat dissipation
● Display: OLED touch screen
● DMX Connectors: IP65 3-pin (Seetronic)
● Power Connectors: IP65 (Seetronic PowerCON style)
● Ingress Protection Rating: IP65
● Housing Material: Die-cast aluminum
● Product Dimensions (including bracket height): L100×W12.5×H15 cm
● Packing Dimensions: 101×15×18 cm (single); 106×34×40 cm (4in1)
● Net Weight: 7.6 kgs
● Gross Weight (single): 8.5 kg; (4in1): 38.0 kg
