WOP-AD8 ArtNet-DMX Converter 8
Engineered for lighting professionals who demand reliability and flexibility, the WOP-AD8 is a powerful ArtNet-to-DMX converter and signal splitter in a compact 19" 1U rack-mountable chassis. Whether you're programming large-scale concert visuals, managing theatrical productions, or setting up for corporate events and festivals, this device ensures seamless signal conversion with zero connection delay.
Choose between two splitter modes—2 inputs to 4 outputs, or 1 input to 8 outputs—to adapt to any rig configuration. All 8 DMX outputs are fully opto-isolated, guaranteeing 100% electrical insulation between ports, so a fault on one line never compromises the rest of your system. The intuitive TFT display and real-time LED indicators provide clear status monitoring, while adjustable DMX frequency up to 40 Hz/sec ensures smooth, flicker-free performance.
Built for the road and ready for the stage, the WOP-AD8 delivers rock-solid signal distribution where it matters most.
Model Name: WOP-AD8
Product Name: ArtNet-DMX Converter 8
Product Description: Professional signal conversion and transmission device designed for ArtNet to DMX signal conversion and distribution, featuring high stability and fast transmission performance.
Technical Parameters
● Function: ArtNet/DMX signal conversion and transmission, with switchable DMX splitter operation modes
● DMX Splitter Modes (Switchable):
Mode 1: 2 DMX Inputs - 4 DMX Outputs
Mode 2: 1 DMX Input - 8 DMX Outputs
● DMX Input Channels: 2 opto-isolated DMX input channels (2 DMX In)
● DMX Output Channels: 8 opto-isolated DMX output channels (8 DMX Out)
● Connection: Ethernet I/O high-speed connection, zero connection delay
● Supported Protocols: Art-Net, sACN, DMX 512
● DMX Frequency: Adjustable, up to 40 Hz/sec
● DMX Ports: 3-pin XLR
● Electrical Insulation: 100% electrical insulation between all input and output ports; issues with one port will not affect others
● Display & Indication: Equipped with a TFT display for device parameter settings; LED indicators for each input and output port (real-time working status display)
● Installation: Rack-mountable or truss-mountable (with M12 bolt holes)
● Finture Dimension: 19" 1U, 485×170×45mm (L×W×H)
● Net Weight: 2kg
